Product Introduction

The Overmolded M12 Unshielded Circular Connector is designed for compact signal and power transmission where reliable connection, flexible cabling, and simplified installation are required. By combining a standardized M12 interface with an integrated overmolded structure, this connector delivers stable performance in demanding industrial environments while maintaining cost efficiency through its unshielded design.

Unlike traditional field-assembled connectors, the overmolded construction creates a sealed transition between cable and connector, reducing mechanical stress, minimizing ingress risks, and improving long-term durability. The unshielded configuration makes this connector especially suitable for applications where electromagnetic interference is not critical, allowing system designers to balance performance with overall system cost.

This connector series is widely adopted in automation, sensor networks, and industrial equipment where space, reliability, and ease of deployment are key decision factors.

Product Features

Integrated Overmolded Construction

One-piece molding between cable and connector housing

Enhances strain relief and reduces cable bending fatigue

Improves resistance to vibration and mechanical movement

Standard M12 Interface

Fully compatible with common M12 mating standards

Ensures easy integration into existing systems

Supports standardized installation and replacement

Unshielded Electrical Design

Optimized for applications with low EMI sensitivity

Reduces material complexity and overall connector weight

Supports stable signal and power transmission in controlled environments

Compact and Space-Efficient Form Factor

Ideal for dense installations and limited mounting spaces

Clean cable exit improves routing flexibility

Suitable for panel-mounted or free-hanging applications

Reliable Environmental Protection

Overmolded housing enhances resistance to dust and moisture

Maintains stable performance under frequent handling

Suitable for indoor and light outdoor industrial use

Product Advantages

Simplified Installation and Reduced Assembly Time

The factory-overmolded design eliminates the need for on-site wiring or termination, helping installers achieve faster and more consistent connections.

Improved Mechanical Reliability

By reinforcing the cable-to-connector junction, the overmolded structure significantly reduces failure caused by pulling, twisting, or repeated movement.

Cost-Effective System Design

The unshielded configuration offers a practical solution for systems that do not require EMI shielding, allowing for optimized cost without compromising reliability.

Consistent Quality Across Batches

Pre-assembled construction ensures uniform electrical and mechanical performance, supporting large-scale deployment and standardized maintenance.

Flexible System Integration

Compatible with a wide range of sensors, actuators, and control modules, making it suitable for diverse industrial architectures.

Product Applications

The Overmolded M12 Unshielded Circular Connector is commonly used in applications where stable connectivity and installation efficiency are essential, including:

Industrial automation systems

Sensor and actuator connections

Factory equipment and machinery wiring

Control cabinets and distributed I/O systems

Robotics peripheral connections

Conveying and material handling equipment

Its design supports environments where durability and simplicity are more important than electromagnetic shielding.

Frequently Asked Questions (FAQ)

Q1: What is the main benefit of an overmolded M12 connector?
The overmolded structure improves strain relief, reduces mechanical stress, and enhances long-term reliability compared to field-assembled connectors.

Q2: When should an unshielded M12 connector be selected?
Unshielded connectors are suitable for applications with minimal electromagnetic interference, offering a cost-effective and lightweight solution.

Q3: Is this connector compatible with standard M12 ports?
Yes. It follows standard M12 interface specifications and can be directly mated with common M12 devices.

Q4: Can this connector handle frequent movement or vibration?
Yes. The reinforced cable exit and molded housing help absorb mechanical stress caused by movement or vibration.

Q5: Is customization available for cable length or pin configuration?
Cable length, conductor specifications, and pin layouts can be adapted based on project requirements.
