Product Parameters

Specifications

current rating:3-5A

contact resistance:<50mΩ

spring force:2.0N

max.travel:1.3mm

bandwidth:-0.1db@6GHZ

test in good situation by pressing1/2-2/3 teavel.

Materials and plating

spring:music wire,gold plated

dielectric insulator:teflon

shielding tube:brass gold plated

signal plunger:be cu gold plated

base:Copper alloy

Product Introduction

The A070 Precision RF Interconnect System is developed to address these expectations. Designed by YFS Technology (SZ) Co., Ltd., this RF connector series focuses on maintaining signal continuity, mechanical alignment, and long-term interface integrity, making it suitable for RF architectures that demand repeatable and controllable connections.

Rather than positioning itself as a single-purpose RF connector, the A070 series is engineered as a stable RF interface solution, supporting system designers who prioritize consistency, durability, and integration efficiency.

Product Overview

The A070 RF interconnect system is a coaxial-based RF connector series designed to provide a controlled electrical interface between RF modules, boards, and subsystems. Its internal structure is optimized to support stable impedance behavior and minimize interface-related signal deviation.

By combining precision-machined conductive components with carefully selected dielectric materials, the A070 series ensures that RF signals remain stable throughout repeated mating cycles. This makes it especially valuable in systems where connectors are frequently connected, disconnected, or repositioned during testing and operation.

The design philosophy behind the A070 series emphasizes engineering reliability over specification inflation, helping users achieve dependable RF performance in practical applications.

Key Product Features

Controlled Impedance Structure

The internal geometry of the A070 RF series is designed to maintain consistent impedance across the connector interface, helping reduce signal reflection and insertion variability.

Precision Contact Alignment

Accurate alignment between inner and outer conductors improves electrical continuity and minimizes micro-discontinuities that can affect RF signal quality.

Repeatable Connection Performance

The connector structure is optimized to deliver consistent RF behavior even after multiple mating cycles, supporting both development and operational use.

Robust Mechanical Stability

The A070 series provides stable mechanical engagement, reducing the risk of signal degradation caused by vibration, movement, or assembly tolerance variations.

Modular Compatibility

Designed to integrate smoothly into different RF system layouts, the A070 series supports flexible system design without compromising RF integrity.

Product Advantages

Enhanced System-Level Reliability

By focusing on interface stability rather than isolated performance metrics, the A070 RF Interconnect System improves overall RF system reliability.

Reduced Debugging and Rework

Stable and predictable connector behavior helps engineers identify true system-level issues, reducing time spent troubleshooting connector-related uncertainties.

Optimized for Practical Engineering Use

The A070 series is designed to perform consistently under real-world conditions, not just under ideal test setups.

Long-Term Design Value

Its durable structure and stable electrical performance make the A070 RF system suitable for long-term deployment and iterative product development.

Backed by RF Manufacturing Expertise

Developed and produced by YFS Technology (SZ) Co., Ltd., the A070 series benefits from controlled manufacturing processes and focused RF engineering support.

Product Applications

RF Module Interconnection

Used to connect RF modules within communication systems, ensuring stable signal transfer between functional blocks.

Measurement and Calibration Systems

Suitable for RF measurement setups where connection repeatability is essential for accurate data comparison.

Embedded RF Subsystems

Integrated into compact RF-enabled devices that require consistent signal paths within limited space.

Industrial RF Equipment

Applied in RF-based industrial electronics where mechanical stability and signal integrity are both critical.

Engineering Validation and Prototyping

Used in development environments where RF systems undergo frequent configuration changes.

Frequently Asked Questions (FAQ)

Q1: What distinguishes the A070 RF Interconnect System from standard RF connectors?
The A070 series focuses on system-level signal stability and repeatable interface performance rather than only meeting frequency specifications.

Q2: Is the A070 series suitable for repeated connection and disconnection?
Yes. Its contact and alignment design supports consistent RF behavior across multiple mating cycles.

Q3: Can this RF series support compact system designs?
The A070 RF system is designed to integrate efficiently into space-constrained RF assemblies.

Q4: Is the A070 RF Interconnect System intended for long-term use?
Its mechanical durability and electrical consistency make it suitable for long-term operation and iterative development.

Q5: Who develops and manufactures the A070 RF series?
The A070 RF Interconnect System is developed by YFS Technology (SZ) Co., Ltd.
