Product Parameters

Specifications

current rating/:3-5A

contact resistance:<50mΩ

spring force:2.5N

max.travel:2.8mm

bandwidth:-0.15db@6GHZ

vswr/:≤1.45(DC-6GHz)

insertion loss:≤0.50dB(DC-6Ghz)

Materials and plating

spring:music wire,gold plated

dielectric insulator:teflon

shielding tube:brass gold plated

signal plunger:be cu gold plated

the base:Nickel plating on stainless steel

Product Introduction

In modern RF systems, signal quality is no longer determined solely by circuit design. The reliability of the RF connector itself plays a critical role in maintaining signal stability, minimizing loss, and ensuring long-term system consistency. Engineers searching for RF connectors today are not simply looking for compatibility—they are looking for predictable performance, mechanical stability, and design confidence.

The D045 RF series connector is developed to meet these expectations. Designed by YFS Technology (SZ) Co., Ltd., this RF connector series focuses on providing a balanced RF interconnection solution where electrical performance and mechanical integrity work together as a unified system.

Rather than positioning itself as a universal connector for all scenarios, the D045 RF Series emphasizes precision RF transmission and structural reliability, making it an ideal choice for RF systems that require stable performance over extended service life.

Product Series Overview

The D045 RF Series Connector is a family of RF interconnects built around a consistent coaxial structure. The series is engineered to maintain controlled impedance and stable contact behavior across repeated mating cycles and long-term operation.

Each connector in the D045 series follows the same design philosophy: minimize signal disturbance while maintaining mechanical robustness. This makes the series suitable for projects where RF integrity must be preserved throughout manufacturing, assembly, testing, and final deployment.

By offering a standardized RF interface, the D045 series helps engineers simplify RF system layouts and reduce variation across different device configurations.

Product Features

Precision RF Transmission Design

The internal structure of the D045 RF Series Connector is optimized for controlled RF signal flow. Carefully aligned conductors and dielectric components help reduce impedance fluctuation and signal reflection.

Stable Mechanical Interface

The connector is designed to maintain consistent contact pressure, supporting reliable electrical connection even after repeated insertions and removals.

Consistent Performance Across the Series

All connectors within the D045 RF Series share unified electrical and mechanical characteristics, allowing predictable behavior during system integration.

Compact and Balanced Structure

The compact form factor supports efficient PCB layout while maintaining sufficient mechanical strength for reliable installation.

Designed for Long-Term Use

Material selection and structural design focus on maintaining performance stability over time, even under demanding operating conditions.

Product Advantages

Enhanced Signal Reliability

The D045 RF Series helps reduce common RF issues such as intermittent contact, signal drift, and unstable impedance, contributing to cleaner and more consistent RF transmission.

Simplified System Design

With a standardized RF interface, engineers can design systems with fewer variables, reducing development time and simplifying validation processes.

Improved Assembly Confidence

The stable mechanical design supports consistent installation results, minimizing variation during manufacturing and assembly.

Suitable for Scalable Product Lines

The series-based structure allows the same RF connector family to be used across multiple devices or system generations, supporting long-term product planning.

Developed by an Experienced RF Connector Manufacturer

Designed and produced by YFS Technology (SZ) Co., Ltd., the D045 RF Series reflects practical experience in RF interconnection technology and manufacturing control.

Product Applications

RF Communication Modules

Used in RF modules where stable signal transmission and repeatable performance are essential for system reliability.

Measurement and Test Systems

Applied in RF test equipment and signal measurement setups that require consistent connector behavior over repeated connection cycles.

Embedded RF Electronics

Suitable for embedded systems integrating RF functionality, where space efficiency and signal stability must be balanced.

Industrial RF Systems

Used in industrial electronic systems that rely on RF signal transmission under continuous operation conditions.

Research and Engineering Platforms

Supports R&D environments where RF designs are evaluated, refined, and validated.

Frequently Asked Questions (FAQ)

Q1: What is the main focus of the D045 RF Series Connector?
The D045 RF Series is designed to provide stable RF transmission and reliable mechanical performance for precision RF systems.

Q2: Is the D045 RF Series suitable for long-term operation?
Yes. The series is designed with long-term performance stability in mind, focusing on consistent contact behavior and signal integrity.

Q3: Can the D045 RF Series be used across multiple products?
The standardized design makes it suitable for use across different devices and system configurations.

Q4: How does the D045 RF Series support system reliability?
By maintaining controlled impedance and stable mechanical contact, the connector helps reduce RF performance variation over time.

Q5: Who manufactures the D045 RF Series Connector?
The D045 RF Series Connector is developed and manufactured by YFS Technology (SZ) Co., Ltd.
