Parameters

duribility:10,000 cycles

Rated Current:20A-120A

Temperature Rise:30K maximum.

BTB connecting distance:H±0.50mm(customizable)

Product Introduction

The High-Stability Industrial Board-to-Board Connector is engineered to deliver secure and consistent PCB-to-PCB interconnections in electronic systems where operational reliability and mechanical stability are critical. Designed for internal board stacking and modular circuit integration, this connector supports stable signal and power transmission while maintaining precise alignment between mating boards.

Developed by YFS Technology (SZ) Co., Ltd, this board-to-board connector reflects a solution-driven design philosophy. Instead of focusing solely on pin count or form factor, the product is optimized around real-world application demands such as vibration resistance, contact durability, and long-term electrical consistency. It is particularly suitable for equipment that operates continuously or in environments where signal interruption is unacceptable.

By balancing compact structure with robust mechanical performance, this connector enables engineers to simplify internal wiring, improve system integration efficiency, and reduce maintenance risks over the product lifecycle.

Product Features

Stable Contact System

The connector utilizes a refined contact structure that ensures uniform contact pressure across all terminals. This helps maintain stable electrical continuity even after repeated mating cycles or prolonged operation.

Controlled Mechanical Tolerance

Precise dimensional control minimizes misalignment between boards, reducing mechanical stress during assembly and long-term use.

Compact Profile for PCB Stacking

The low-profile design supports multi-board stacking while preserving valuable internal space, making it suitable for compact electronic architectures.

Enhanced Vibration Resistance

The connector structure is optimized to reduce micro-movement between contacts, improving performance in vibration-prone environments.

Consistent Electrical Performance

Designed to support reliable transmission of signals and power, the connector helps reduce the risk of signal loss, impedance fluctuation, or intermittent contact.

Product Advantages

Designed for Industrial Reliability

Unlike general-purpose connectors, this board-to-board connector is optimized for industrial and professional electronic systems that require stable operation over long periods.

Reduced System Integration Complexity

By providing a dependable PCB interconnection solution, the connector simplifies internal layouts and reduces the need for additional wiring or reinforcement components.

Long Service Life

Carefully selected materials and contact structures help maintain performance stability over extended mating cycles, lowering replacement and maintenance costs.

Assembly-Friendly Design

The connector is compatible with standard SMT processes, enabling efficient automated assembly and consistent production quality.

Solution Support from a Connector Specialist

YFS Technology offers technical support throughout the project lifecycle, assisting customers in selecting suitable connector configurations for their specific applications.

Product Applications

The High-Stability Industrial Board-to-Board Connector is widely used in electronic systems where reliable internal connections are essential:

Industrial automation and control modules

Communication and networking equipment

Medical electronic devices and monitoring systems

Automotive electronic control units

Robotics and intelligent manufacturing equipment

UAV systems and embedded control platforms

Power management and control boards

Frequently Asked Questions (FAQ)

Q1: What is the primary purpose of this board-to-board connector?
A: It is designed to provide reliable internal PCB-to-PCB connections for signal and power transmission in compact and modular electronic systems.

Q2: Is this connector suitable for continuous operation environments?
A: Yes. The connector is designed to maintain stable electrical and mechanical performance during long-term and continuous operation.

Q3: Can it be used in vibration-sensitive applications?
A: The connector features enhanced vibration resistance, making it suitable for industrial equipment and mobile electronic systems.

Q4: Does the connector support automated assembly processes?
A: Yes. The design is compatible with standard SMT assembly, supporting efficient mass production.

Q5: Can YFS Technology provide customized board-to-board connector solutions?
A: Yes. Custom configurations such as pin layout, stacking height, and mechanical structure can be developed based on project requirements.
