Parameters

duribility:10,000 cycles

Rated Current:20A-120A

Temperature Rise:30K maximum.

BTB connecting distance:H±0.50mm(customizable)

Product Introduction

Low-Profile Structure Board-to-Board Connectors are designed for electronic products where vertical space is extremely limited. By reducing connector height while maintaining stable electrical contact, this type of board-to-board connector supports thinner device designs and higher internal integration levels.

At YFS Technology (SZ) Co., Ltd, low-profile structure board-to-board connectors are developed with a clear focus on mechanical compactness, installation accuracy, and connection stability. These connectors are not simply downsized versions of standard products; they are engineered to balance reduced height with reliable contact performance and structural strength.

Such connectors are widely used in compact electronic systems that require efficient board-level interconnection without increasing enclosure thickness.

Product Description

As electronic devices continue to move toward thinner and lighter designs, internal connection components must occupy less space without compromising performance. Low-profile structure board-to-board connectors allow multiple circuit boards to be connected within minimal vertical clearance.

YFS Technology designs this connector category with careful control of mating tolerance, contact pressure, and housing structure. The reduced profile helps optimize internal layout while ensuring secure engagement between boards during assembly and operation.

This product category is suitable for applications where space efficiency is a primary design driver.

Product Features

Reduced Connector Height

Optimized structure minimizes vertical space consumption within electronic assemblies.

Stable Electrical Contact

Contact design ensures consistent electrical transmission despite compact dimensions.

Accurate Mating Alignment

Precision-guided mating helps prevent installation errors and mechanical stress.

Lightweight Structural Design

Supports overall product weight reduction without sacrificing connection reliability.

Assembly Efficiency

Designed for smooth installation in high-density electronic assemblies.

Product Advantages

Space-Oriented Design Strategy

YFS Technology focuses on solving vertical space constraints while maintaining dependable inter-board connectivity.

Structural Optimization

Housing and contact layout are engineered to deliver stable performance within limited space.

Manufacturing Precision

Controlled production processes ensure consistency across compact connector designs.

Improved Design Flexibility

Low-profile connectors enable more freedom in PCB stacking and enclosure design.

Compatibility with System Solutions

This product integrates easily into complete connector and interconnection solution architectures.

Product Applications

Low-profile structure board-to-board connectors are commonly used in applications that require compact form factors:

• Medical diagnostic devices

• Portable electronic equipment

• Embedded control modules

• Communication terminals

• UAV onboard electronics

• Compact industrial devices

• Space-constrained electronic assemblies

These applications benefit from reduced internal height and reliable board-level connections.

Product Details

This category of low-profile structure board-to-board connectors is available in various configurations to meet different design requirements. Connector structure emphasizes consistent contact performance, accurate mating, and long-term reliability despite compact dimensions.

Material selection and surface finishing are optimized to maintain stable electrical behavior and mechanical durability. Each design supports dependable performance throughout the product lifecycle.

Frequently Asked Questions (FAQ)

Q1: What is the main benefit of a low-profile board-to-board connector?
It reduces vertical space usage while maintaining stable electrical connections between boards.

Q2: Does reducing connector height affect reliability?
When properly designed, low-profile connectors maintain reliable contact performance and structural stability.

Q3: Are these connectors suitable for compact device manufacturing?
Yes. They are specifically designed for space-limited electronic products.

Q4: Can low-profile connectors support repeated installation?
They are designed to maintain stable performance under controlled mating cycles.

Q5: How do these connectors help with product miniaturization?
By minimizing internal connector height, they allow thinner device designs and higher integration density.
